The Guide on How to Set Up Reloading Dies for a Rifle



Having a thorough knowledge of setting up your reloading dies is a crucial step to getting started. If you don’t set your reloading dies properly, there’s a high chance for your ammo to be inaccurate, unreliable, and even risky.

Most reloading Dies for ammunition come with instructions carrying a proper explanation. You should always follow the manufacturer’s guidelines, especially when dealing with specialty dies.

So, if you have already purchased Rifle Reloading Dies for sale, scroll through the below-mentioned instructions for setting up reloading dies.

How to Set Up a Rifle Reloading Die

The first step to get on the reloading process is to full-length your brass. Full-length sizing is the most viable method for resizing most types of brass as it will turn back to its original factory specifications. This helps to push it forth to the chamber and cycle reliably, which is crucial when reloading for semi-automatic rifles or pistols.

A full-length sizing die will remove the spent primer. The part of the die is known as a decapping pin. This pin must be protruding from a proper distance. If it doesn’t protrude enough, it won’t be able to remove the primer. Thus, this could result in the case getting stuck in the shell holder.

How to Adjust the Decapping Pin (Rod)

  • Loosen the round lock nut present at the top of the die.

  • Move the screw to adjust the decapping pin.

  • Lastly, tighten the lock nut.



Resizing Dies

  • Lodge the resizing die into your press.

  • Look for a 3/4-inch and 1/2-inch box wrench.

  • Use the wrenches to loosen the decapping rod collet.

  • When you are trying to loosen the collet you will need to exert a little bit of force.

  • Slide in the decapping pin’s depth while the collet is loose.

  • Tighten the collet. Be careful not to lose your newly-adjusted decapping pin depth. Also, make sure to well-tighten the collet. In case you don’t, the pin will come out while decapping a case.

How to Set Up Dies on Your Reloading Press

  • Place a proper shell holder into your press.

  • Level the ram on your reloading press to the top.

  • Loosen the large lock ring on the die.

  • Turn the die into the press until it reaches the top of the shell holder.

  • Lower the press’s ram.

  • Turn the die one more quarter; then it turns into the press.

  • Lower the press’s ram again, helping it to come over.

  • Turn the lock ring till it can touch the top of your press.

  • Tighten the lock ring’s set screw and set your adjustment.

  • Check your adjustment by raising the ram. The shell holder should reach the bottom of the die before the press handle is down. Once it’s done, see if you are still able to lower the handle or not.

In The End

Alas, with all the information, the basis for reloading Dies for ammunition shouldn’t look
like rocket science, or you can’t D.I.Y with no hassle.
